SPECIFICATION
|
|
Product Name | ANTILA D5 RBW |
Product Number | 0R40B00109 |
Q'ty | 1 pcs |
Dimension [W×H×D] | 87.4×280.6×91.2 mm [with Bracket] |
Reservoir Dimension | Φ64×205[H] mm |
Material | POM + PMMA (Crystal clear) |
Weight | 790 g |
Screw Threads | G 1/4" |
Bearing type | Ceramic Bearing |
Maximum Head | 3.85m |
Maximum Discharge | 900 L/H |
Maximum Pressure | 50 PSI |
Life Expectance | 50,000 hrs |
Noise Level | 30 dBA [Max.] |
Speed | P1 : 1,800 RPM P2 : 2,500 RPM P3 : 3,200 RPM P4 : 3,900 RPM P5 : 4,500 RPM |
Voltage Rating | DC12V |
Input Current | 1.8 A ± 10% |
Connector | 2606-H-03P [-12V/+12V] / 2510-4P [NA / NA / Fg / PWM] |
Addressable LED | 21 LED Rainbow (4pin header, 2510 spec) – Addressable LED |
LED Control Method | Motherboard control / Remote control (by using Raijintek control hub) |
LED Input Connector | 4-PIN header (2.5 Crimp) |
LED Voltage Rating | 5V |
Lighting Mode | By MB software or 20 Lighting MODE & 7 different static color choices by Raijintek's 5V ADD control hub |
