| CPU hỗ trợ |
AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors |
| Chipset |
AMD B850 Chipset |
| RAM hỗ trợ |
4 x DIMM slots, max. 256GB, DDR5 Supports up to 8000+MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC, Un-buffered DIMMDual channel memory architectureSupports AMD Extended Profiles for Overclocking (EXPO™)ASUS Enhanced Memory Profile (AEMP) |
| Đồ họa |
1 x DisplayPort1 x HDMI port1 x USB4 (40Gbps) port supports USB Type-C® display outputs |
| Khe cắm mở rộng |
AMD Ryzen 9000 & 7000 Series Desktop Processors1 x PCIe 5.0 x16 slot with Q-Release Slim (supports x16 or x8 modes)AMD Ryzen 8000 Series Desktop Processors1 x PCIe 5.0 x16 slot with Q-Rlease Slim (supports PCIe 4.0 x8 or x4 mode) AMD B850 Chipset1 x PCIe 4.0 x16 slot (supports x4 mode) |
| Ổ cứng hỗ trợ |
Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen™ 9000 & 7000 Series Desktop ProcessorsM.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)M.2_3 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) AMD Ryzen™ 8000 Series Desktop ProcessorsM.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280/22110 (Not supports)M.2_3 slot (Key M), type 2280 (Not supports) AMD B850 ChipsetM.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_5 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode) ASMedia ASM1061 Controller4 x SATA 6Gb/s ports |
| ETHERNET |
1 x Realtek 5Gb EthernetASUS LANGuard |
| LAN / Wireless |
Wi-Fi 72x2 Wi-Fi 7 (802.11be)Supports 2.4/5/6GHz frequency bandSupports Wi-Fi 7 320MHz bandwidth, up to 6.5Gbpstransfer rate.Bluetooth v5.4 |
| USB |
Rear USB (Total 12 ports)1 x USB4® (40Gbps) port(1 x USB Type-C®)1 x USB 20Gbps port (supports USB Type-C® with up to 30W PD/PPS Fast-charge)6 x USB 10Gbps ports (6 x Type-A)4 x USB 2.0 ports (4 x Type-A) Front USB (Total 7 ports)1 x USB 10Gbps connector (1 x USB Type-C®)1 x USB 5Gbps header supports 2 additional USB 5Gbps ports2 x USB 2.0 headers support 4 additional USB 2.0 ports |
| Cổng kết nối (Internal) |
Fan and Cooling Related1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header5 x 4-pin Chassis Fan headers Power Related1 x 24-pin Main Power connector2 x 8-pin +12V CPU Power connector Storage Related5 x M.2 slots (Key M)4 x SATA 6Gb/s ports USB1 x USB 10Gbps connector (supports USB Type-C® )1 x USB 5Gbps header supports 2 additional USB 5Gbps ports2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous3 x Addressable Gen 2 header(s)1 x CPU Over voltage jumper1 x Front Panel Audio header (F_AUDIO)1 x Power button1 x 10-1 pin Front System Panel header1 x Thermal Sensor header |
| Cổng kết nối (Back Panel) |
1 x USB4 (40Gbps)(1 x USB Type-C)1 x USB 20Gbps port (supports USB Type-C® with up to 30W PD/PPS Fast-charge)6 x USB 10Gbps ports (6 x Type-A)4 x USB 2.0 ports (4 x Type-A)1 x DisplayPort1 x HDMI™ port1 x Wi-Fi module1 x Realtek 5Gb Ethernet port2 x Gold-plated audio jacks1 x Optical S/PDIF out port1 x BIOS FlashBack™ button1 x Clear CMOS button |
| Âm thanh |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080- Impedance sense for front and rear headphone outputs- Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking- High quality 120 dB SNR stereo playback output and 110 dB SNR recording input- Supports up to 32-Bit/384 kHz playback on front panel Audio Features- SupremeFX Shielding Technology- Savitech SV3H712 AMP- Gold-plated audio jacks- Rear optical S/PDIF out port- Premium audio capacitors- Audio cover |
| Kích cỡ |
ATX Form Factor12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
