| CPU |
LGA1151 socket for 8th Generation Intel® Core™ i7 / i5 / i3 / Pentium® / Celeron® Processors |
| Supports 14nm CPU |
| Supports Intel® Turbo Boost Technology 2.0* |
| * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. |
| ** Refer to www.asus.com for Intel® CPU support list. |
| Chipset |
Intel® H310 Chipset |
| Memory |
2 x DIMMs, maximum 32 GB, DDR4 2666/ 2400/ 2133 MHz, non-ECC, un-buffered memory |
| Dual channel memory architecture |
| Supports Intel® Extreme Memory Profile (XMP) |
| * The maximum memory frequency supported varies by processor. |
| ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors. |
| ***Refer to www.asus.com for the Memory QVL (Qualified Vendors List). |
| Expansion Slots |
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode) |
| 2 x PCI Express 2.0 x1 slots |
| VGA |
Integrated Graphics Processor – Intel®HD Graphics support |
| Multi-VGA output support: HDMI, D-Sub ports |
| – Supports HDMI 1.4b with max.resolution up to 4096 x 2160 @24Hz / 2560 x 1600@60Hz |
| – Supports D-Sub with max. resolution up to 1920 x 1200 @60Hz |
| Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™ |
| Maximum shared memory of 1024MB |
| Storage |
Intel® H310 Chipset |
| – 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support(both SATA & x2 PCIE mode)* |
| – 4 x Serial ATA 6.0 Gb/s connectors (gray) |
*When a device in SATA mode is installed on the M.2 socket,SATA_2 port cannot be used.
Due to the Chipset limitation, when an M.2 device is installed in PCIe mode, the socket is set to PCIe 2.0. |
| LAN |
Realtek® 8111H Gigabit LAN controller support LANGuard |
| Audio |
Realtek® ALC887 8-channel high definition audio CODEC |
| – LED-illuminated design: Brighten up your build with the gorgeous illuminated audio trace path |
| – Audio Shielding: Ensures precision analog/digital separation and greatly reduces multi-lateral interference |
| – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals |
| – Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity |
| – Supports jack-detection and front panel jack-retasking |
| * Choose the chassis with HD audio module in front panel to support 8-channel audio output. |
| USB |
Intel® H310 Chipset |
| – 4 x USB 3.1 Gen 1(up to 5Gbps) ports (2 ports @mid-board; 2 ports @back panel, blue, Type A) |
| – 6 x USB 2.0/1.1 ports (4 ports @ mid-board, 2 ports @ back panel) |
| ASUS Special Features |
ASUS 5X PROTECTION III |
| – ASUS SafeSlot Core: Fortified PCIe Slot prevents damage |
| – ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges |
| – ASUS Overvoltage Protection: World-class circuit-protecting power design |
| – ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability |
| – ASUS DIGI+ VRM – 4 Phase digital power design |
| Superb Performance |
| ASUS OptiMem |
| – Improved DDR4 stability |
| M.2 onboard |
| – The latest transfer technologies with up to 10Gb/s data transfer speeds |
| ASUS EPU |
| – EPU |
| UEFI BIOS |
| – Most advanced options with fast response time |
| Gaming Scenario |
| Audio Features |
| – Audio that roars on the battlefield |
| ASUS Exclusive Features |
| – ASUS AI Charger |
| – ASUS AI Suite 3 |
| – ASUS file transfer |
| – ASUS PC Cleaner |
| EZ DIY |
| UEFI BIOS EZ Mode |
| – featuring friendly graphics user interface |
| – ASUS CrashFree BIOS 3 |
| – ASUS EZ Flash 3 |
| ASUS Q-Design |
| – ASUS Q-DIMM |
| ASUS Quiet Thermal Solution |
Quiet Thermal Design: |
| – Stylish Fanless Design: PCH heatsink solution |
| – ASUS Fan Xpert |
| Back Panel I/O Ports |
1 x PS/2 Keyboard/Mouse combo port |
| 2 x USB 3.1 Gen 1 ports (up to 5Gbps) Type A (blue) |
| 2 x USB 2.0/1.1 ports |
| 1 x HDMI port |
| 1 x D-Sub port |
| 1 x LAN (RJ-45) port |
| 1 x LPT port |
| 1 x COM port |
| 3 x Audio jacks support 8-channel audio output* |
| * Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
| Internal I/O Connectors |
1 x USB 3.1 Gen 1 (up to 5Gbps) connectors support additional 2 USB ports (19-pin) |
| 2 x USB 2.0/1.1 connectors support additional 4 USB ports |
| 4 x SATA 6.0Gb/s connectors |
| 1 x M.2 Socket 3 (for M Key) |
| 1 x 4-pin CPU Fan connector for 4-pin PWM mode |
| 1 x 4-pin Chassis Fan connector for 3-pin (DC mode) and 4-pin (PWM mode) coolers control |
| 1 x Front panel audio connector(AAFP) |
| 1 x S/PDIF Out connector |
| 1 x 24-pin EATX Power connector |
| 1 x 4-pin ATX 12V Power connector |
| 1 x System Panel connector |
| 1 x Speaker connector |
| 1 x Clear CMOS jumper(2-pin) |
| BIOS |
128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Manageability |
WOL by PME, PXE |
| Accessories |
2 x Serial SATA 6.0Gb/s cables |
| 1 x I/O shield |
| 1 x Support DVD |
| 1 x M.2 Anchor |
| 1 x User’s manual |
| Support DVD |
Drivers |
| ASUS Utilities |
| EZ Update |
| Anti-virus software (OEM version) |
| Operating System Support |
Windows® 10 (64-bit) |
| Form Factor |
uATX Form Factor, 8.9”x 7.3” (22.6cm x 18.5cm) |
