General
Model No.
PH-F120T30_BG | PH-F120T30_BG_3P
UPC Code
886523001829 | 886523001836
Frame Size
120 x 120 x 30 mm | 4.72 x 4.72 x 1.18 in
Blade Geometry
Seven-blades design
Color
Grey
PWM Connector
4-Pin Daisy-chain
PWM Cable Length
130 + 500 mm Extension cable
D-RGB Connector
–
D-RGB Cable Length
–
Technical Details
Bearing Type
VAPO bearing system
Rated Voltage
12V
Max. Noise Level
39.7 dBA
Max. Airflow
100.9 CFM
Max. Air Pressure
7.37 mm H2O
Speed
0~3000 ± 10% RPM
MTFB
150.000 hours
Max. Current
0.41A
Max. Power
4.92W
Operating Voltage Range
DC 10.2 – 13.2V
Fan Profile Specifications
Advanced
Performance
Hybrid
Max. Speed
RPM
3000 ± 150
2000 ± 100
1200 ± 75
Max. Airflow
CFM
100.9
67.0
40.3
Max. Airflow
M3/H
171.4
113.8
68.5
Max. Static Pressure
Inch H2O
0.29
0.13
0.05
Max. Static Pressure
mm H2O
7.37
3.30
1.27
Max. Sound Level
dBA
39.7
27.3
9.8
Max. Current
A
0.41
0.16
0.07
Max. Power
W
4.92
1.92
0.84
Single Pack
Triple Pack
Net Weight
230 ± 5 g | 8.11 ± 0.17 oz
Gross Weight
350 ± 5 g | – ± 12.34 oz
Warranty
6 Years
Scope of Delivery
1x T30-120 fan
Accessories
1x 4-Pin extension cable 500 mm
